Durability, sustainability and cost analysis of the effect of SNF superplasticizers on locally produced concrete in Ghana
by Joseph Ignatius Teye Buertey, Mark Bediako, Emmanuel Appiah-Kubi, Timothy Ametefe
Insight - Civil Engineering, Vol.8, No.1, 2025;
0 Views
Using conventional methods of concrete production to achieve expected results is challenging, hence the use of chemical admixtures which is also little researched in Ghana. The study conducted a concrete mix design for project construction, following significant challenges encountered in attaining the desired strength of 30MPa at a slump of S3 (100-150mm). To address the challenge, a concrete mix design was produced according to EN 206 standard mix design at the laboratory of the Council for Scientific and Industrial Research (CSIR)-Building and Road Research Institute (BRRI)-Ghana. A chemical admixture consisting of high-range water-lowering sulfonated naphthalene formaldehyde (SNF) was used in the design. Once the laboratory mix design was completed, the concrete mix proportions were adopted for field application. When employing 385kg/m 3 of Portland cement, a water-to-cement ratio of 0.49, a water content of roughly 189kg/m 3 , and an admixture content of 3.28kg/m 3 , the laboratory mix design yielded a 28-day compressive strength of 37 MPa (5366 psi). After 28 days of curing, both the laboratory (37MPa) and field-prepared (31MPa) concretes met the minimum strength of 30MPa with the laboratory-controlled concrete exhibiting compressive strength results that were approximately 16% greater than those of the field-prepared concretes. The report revealed that the use of SNF resulted in 18% savings in cement thereby reducing carbon emissions and 5% savings in cost, urging a case for the use of chemical admixtures for structural and non-structural concrete components of the project for the sake of durability, sustainability and cost.
